Roof Sandwich Panels

Description

Built for beauty, durability and value, 5 Ribs Roof polyurethane sandwich panels are roof construction materials that perform in all seasons. Panels have the best thermal insulation with waterproofing and they stand out of long durability of exploitation and easy installation.

Use of these sandwich panels is a great solution for all types of buildings construction, including leisure, hospitals, industrial, retail, commercial, equipment storage, garages, boxes, cold and freeze stores houses and other applications.



  • Strong heat isolation
  • Weather resistance
  • High level of fire resistance
  • High density
  • Design flexibility/simplicity
  • Easy superficial cleaning
  • Minimal weight
  • Relatively cheap to other roof construction materials
Download

Technical Details

Applications: for roofs

Upper side cover material: Prepainted galvanized steel

Lower side cover material: Prepainted galvanized steel or cardboard

Core material: polyurethane (PUR) core

Design: vertical ribbon, trapeze corrugated

Standard Colour: White grey (RAL 9002). Other colours are also available upon request

Width: 1000 mm

Length: Max. 15 m

Polyurethane Thickness: 50 mm – 100 mm

Thickness of Metal Surface: 0.35 mm - 0.6 mm

Polyurethane Density: 40 (±2) kg/m3

Flammability Class: B2
